1. Biaxially oriented polypropylene matte film, coated with silicone on one or both sides, possesses superior smoothness, anti-adhesive,
and abrasion resistance properties. As a result, it finds applications in various fields such as packaging, printing, electronics, labeling,
industrial, and tape industries.
2. In the packaging industry, BOPP matte film with silicone coating enhances the opening performance of food packaging, pharmaceutical
packaging, cosmetic packaging, and other similar applications where easy opening is essential.
3. In the printing industry, the matte film is used for surface treatment of printed materials, creating a more glossy and smooth surface,
resulting in better readability.
4. The film finds a lot of applications in electronic products' packaging, including mobile phones, computers, and others, providing
excellent anti-skid and scratch-resistant protection.
5. Silicone coating on BOPP matte film improves the peeling performance of labels, making them easier to stick and remove in
labeling industries.
6. In the industrial sector, applications include conveyor belts, waterproof rolls, and others, as silicone coating provides increased
abrasion resistance and slip resistance properties.
7. Additionally, the release film is extensively used in sealing tape and silent tape industries.
8. Depending on the silicone coating amount, type, and other matte film properties, the specific applications may vary in different
industries.
Therefore, one should carefully consider all relevant requirements before selecting and using them.
| Name of Comm. | BOPP Matte Double Side Release Film | Model Number | PBIH70-0815 |
| Test Item | Standard Request | Typical Data | Results |
| Appearance | Wrinkle, particle, damage, impurity,contamination | Not allowed | No | Ok |
| Stripe, burst vein, scratch, pucker | Slight allowable | Slight | Ok |
| Number white point & crystal points | Φ0.2-0.5/㎡ | 0-80 | 40 | Ok |
| Φ0.6-1.0/㎡ | 0-20 | 10 | Ok |
| More than Φ1.0/㎡ | Not allowed | 0 | Ok |
| Size | T Avg. | ±5.0% | 71.5 | Ok |
| T Ultimate Deviation | ±6.0% | 3 | Ok |
| T Average Deviation | ±3.0% | 0.2 | Ok |
| | ±2.0% | No | Ok |
| Mechanical Properties | Tensile Strength (MPa) | MD | ≥ 100 | 151 | Ok |
| TD | ≥ 160 | 278 | Ok |
| Elongation @ Break (%) | MD | ≤ 180 | 201 | Ok |
| TD | ≤ 65 | 65 | Ok |
| Shrinkage (%) | MD | ≤ 4.0 | 3.0 | Ok |
| TD | ≤ 2.0 | 0.5 | Ok |
| Friction Coefficient Us/Ud | Inside | 0.25-0.50 | 0.21/0.20 | Ok |
| Outside | 0.25-0.50 | 0.21/0.18 | Ok |
| Glossiness | ≤ 15 | 4.8 | Ok |
| Haze | ≥ 76 | 89 | Ok |
| Release Force | Side A | gf/25mm (20 min.) TESA 7475 Finat 10 | 5-8 | 7.2 | Ok |
| Side B | 10-15 | 14.8 | Ok |
| Subsequent Adhesion Rate | Side A | % (20hr) NITTO 31B Finat 11 | ≥85 | 91 | Ok |
| Side B | ≥85 | 92 | Ok |
| Inspection Conclusion | Fulfill the technical standard |
